The Run Down:

Spartan Turbocharger Systems (S.T.S.) have specially made these turbochargers to help Patrol ZD30 DI owners!
To have a turbocharger that can make big HP and stay reliable at the same time is always the dream!
They spec these units out with the best of the best parts!
They are designed to make up to 30PSI reliably, yet they also lower EGTs, EMP & drive better than your factory ZD30 turbo!
Through vigorous testing they can comfortably say that these units make between 170Whp-190Whp. (Dependent on vehicle set up & tuner)


- Boost rating 16PSI - 30PSI
- 44mm 6+6 blade billet aluminium compressor wheel
- 9 Blade inconel hybrid turbine wheel
- Custom heavy duty bearing
- Oil cooled core
- Designed specifically for ZD30 DI engine
- Direct install, no modification required
- Pre-calibrated vacuum actuator


 Compressor Turbine
Inlet: 3 Inch Inlet: Factory Flange Lubrication: Oil
Outlet: Factory Size Outlet: Factory flange Coolant: N/A
Wheel: 44mm 6+6 Billet Aluminium Wheel: 9 Blade Inconel Hybrid Oil Fittings: Factory
Size: Factory AR.53 Size: Factory AR.64 Coolant Fittings: N/A


Fitting Notes:

The 724639-STS is a 100% direct fit to your Nissan GU Patrol ZD30 with direct injection.
You will require a 3 Inch exhaust system, upgraded intercooler, 30% larger injector nozzles & a custom ECU tune.
(A copy and paste tunes wont work on these turbos)


Purchase this turbo with one of the following products and receive 10% off that item!!!
- Demon Pro Parts Air Box
- Demon Pro Parts Inlet Pipe
- Demon Pro Parts Oil Catch Can
- Tillix Boost Controller
- Tillix Boost Controller & Pickup Adaptor
- Tillix 3" Inlet

Brand: Spartan Turbocharger Systems (STS)
Model: 724639-STS
Part No: 724639-5006S / 724639-5002S / 705954-5009S / 705954-5013S / 705954-5015S/ 769328-5001S / 769328-0001 / 769328-5001
OEM Part No: 14411-VC100 / 14411-2X900 / 14411-2X90A / 14411VS40A / 14411-VS40A
Vehicle: Nissan Patrol GU (Y61) 3.0L ZD30 DI
Cooling: Oil cooled only
Gaskets: This turbo comes with a free complete gasket kit.
Warranty: 12 Months/25,000km - Whichever comes first
Delivery: Free post to Aus wide, normally takes 2-4 days to major cities.
