Spartan Turbo For Toyota Landcruiser 60/70/80/100 Series 1HD/1HZ/12H-T

Speedup Autoparts Pty Ltd SKU: STS_CT26

$1,765.00

Tax includedShipping calculated at checkout

Available Now!

12 Month Warranty

Flag of australia 01

Austrilan Owned & Operated

The Run Down:

Spartan Turbocharger Systems (S.T.S.) have specially made these turbochargers to help Landcruiser owners with 60/80/100/105 Series!
To have a turbocharger that can make big HP and stay reliable at the same time is always the dream!
S.T.S. spec these units out with the best of the best parts!
They are designed to make up to 28PSI reliably, yet they also lower EGTs, EMP & drive better than your factory CT26 turbo!
Through vigorous testing they can comfortably say that these units make between 180Whp-220Whp. (Dependent on vehicle set up & tuner)

Features:

- Boost rating 12PSI - 28PSI
- Anti-surge compressor housing
- 50mm 6+6 blade billet aluminium compressor wheel
- 9 Blade inconel hybrid turbine wheel
- Custom heavy duty dual ball bearing
- Oil & coolant cooled core
- Bolts directly onto your Toyota turbo manifold and dump pipe
- Pre-calibrated vacuum actuator to 14PSI

Specs:

 Compressor Turbine
Core
Inlet: 3 Inch Inlet: Factory Flange Lubrication: Oil
Outlet: Factory Size Outlet: Factory flange Coolant: Yes
Wheel: 50mm 6+6 Billet Aluminium Wheel: 9 Blade Inconel Hybrid Oil Fittings: Supplied
Size: Factory AR. Size: AR.49 Coolant Fittings: AN6



Fitting Notes:

The CT26-STS is a 90% direct fit to your Landcruiser with 1HD-T & 1HD-FTE.
This turbo will bolt up to your existing Toyota turbo manifold and dump pipe. However, the factory oil & coolant lines will not work with this turbo.
This turbo will come with a complete oil feed & return kit.
There is an optional coolant line kit to replace the factory feed and return lines for if you want to have coolant flowing through the turbo.
For the simplest install, we recommend using the S.T.S. coolant line kit if possible.
(1HZ+T & 12H-T engines will not be able to use the optional water line kit.)
100 Series will also need piping mods. You will need to modify your hot side piping & your intake piping to suit the different compressor cover inlet & outlet.

Brand: Spartan Turbocharger Systems (S.T.S.)
Model: CT26-STS
Part No: CT26
OEM Part No: 17201-17010 / 1720117010 / 17201-17020 / 1720117020 / 17201-17030 / 1720117030 / 17201-17040 / 1720117040
Vehicles:
- Toyota Landcruiser 60 (HJ61) 4.0L 12H-T MY85-92
- Toyota Landcruiser 70 (HDJ79) 4.2L 1HD-FTE MY99-07
- Toyota Landcruiser 80 (HDJ80) 4.2L 1HD-T & 1HD-FT MY90-97
- Toyota Landcruiser 80 (HZJ80) 4.2L 1HZ+T MY90-97

- Toyota Landcruiser 100 (HDJ100) 4.2L 1HD-FTE MY98-07
- Toyota Landcruiser 105 (HZJ105) 4.2L 1HZ+T MY98-07
Cooling: Oil & coolant
Oil Lines: This turbo comes with a complete feed & drain line kit.
Coolant Lines: Optional kit can be supplied for 1HD engines.
Gaskets: This turbo comes with a free complete gasket kit.
Warranty: 12 Months/25,000km - Whichever comes first
Delivery: Free post to Aus wide, normally takes 2-4 days to major cities.
